2017 Aluminum is a typical hard aluminum alloy in the Al-Cu-Mg alloy with better overall performance. It features high strength, a certain degree of heat resistance, and can be used as working parts below 150°C.
At temperatures above 125°C, the strength of the 2017 alloy is higher than that of the 7075 aircraft aluminum. The forming properties in the hot state, annealing and new quenching state are better, and the heat treatment strengthening effect is significant, but the heat treatment process is strict.
The corrosion resistance of 2017 aluminum alloy is poor, but it can be effectively protected by covering with pure aluminum; it is easy to produce cracks during welding, but it can be welded or riveted by special technology.
It is widely used in molds, precision parts, rivets, truck hubs, propeller components and various other structural parts.
Chemical Composition
Alloy | Si | Fe | Cu | Mn | Mg | Ni | Cr | Zn | Ti | Standard |
2017 | 0.2-0.8 | 0.70 | 3.5-4.5 | 0.4-1.0 | 0.4-0.8 | - | 0.10 | 0.25 | 0.15 | GB/T3190 EN573 ASTM B209 |
Mechanical Properties
Alloy | Temper | Thickness(mm) | Tensile Strength Rm(Mpa) | Yield Strength RP0.2(Mpa) | Breaking Elongation A50% | Standard |
2017 | T4 | 0.3-3.5 | 395-405 | 255-270 | 19-23 | GB/T3880 EN485 ASTM B209 |
Size
Alloy | Temper | Thickness(mm) | Width(mm) |
2017 | T4/T3 | 0.3-4.0 | 1000-2600 |
Machinability is very good for this alloy in the T4 temper. In the annealed condition machinability is less good. Thus it is best to perform machining with the alloy in the T4 condition. Use of oil lubricants is recommended for all machining operations.
Formability is very good, especially in the annealed state ("O" temper). The alloy may also be readily formed when in the T4 temper, but not as easily as for the "O" temper.
The alloy may be solution annealed at 940 F for 3 to 4 hours followed by water quench. Age hardening then occurs at room temperature and this produces the T4 temper. The "O" temper results from a 775 F treatment for 3 hours, controlled cooling at 50 F per hour down to 500 F, then air cool.
